Dimensions & Performance
| Specification | US Measurement | Metric |
|---|---|---|
| Working Height (max) | 186 ft | 56.86 m |
| Platform Height (max) | 180 ft | 54.86 m |
| Horizontal Reach (max) | 80 ft | 24.38 m |
| Below Ground Reach | 2 ft | 0.61 m |
| Platform Length | 3 ft | 0.91 m |
| Platform Width | 8 ft | 2.44 m |
| Height – Stowed | 10 ft | 3.05 m |
| Length – Stowed | 53 ft 1 in | 16.18 m |
| Length – Storage/Transport | 42 ft 8 in | 13 m |
| Ground Clearance – Center | 1 ft 3 in | 0.38 m |
| Height Under Counterweight | 4 ft 1 in | 1.24 m |
Width & Wheelbase (Axle Configuration)
| Configuration | Width | Wheelbase |
|---|---|---|
| Axles Retracted | 8 ft 2 in / 2.49 m | 16 ft 6 in / 5.03 m |
| Axles Extended | 16 ft 6 in / 5.03 m | 15 ft 6 in / 4.72 m |
Productivity & Capacity
| Feature | Specification |
|---|---|
| Lift Capacity (max) – Unrestricted | 750 lb / 340 kg |
| Platform Occupants | 2 |
| Platform Rotation | 160° |
| Jib Length | 10 ft / 3.05 m |
| Vertical Jib Rotation | 135° (up/down) |
| Horizontal Jib Rotation | 60° |
| Turntable Rotation | 360° |
Turntable Tailswing
| Axle Configuration | Tailswing |
|---|---|
| Axles Retracted | 3 ft 9 in / 1.14 m |
| Axles Extended | 3 ft 6 in / 1.07 m |
Drive Performance
| Feature | Specification |
|---|---|
| Drive Speed – Stowed | 2.3 mph / 3.7 km/h |
| Drive Speed – Raised | 0.4 mph / 0.65 km/h |
| Gradeability – Stowed | 35% |
| Tilt Sensor Activation | 4.5° (front to back) / 3° (side to side) |
| Tires | 445D50 / 710 |
Turning Radius
| Axle Configuration | Inside Radius | Outside Radius |
|---|---|---|
| Axles Retracted | 20 ft 7 in / 6.28 m | 28 ft 1 in / 8.56 m |
| Axles Extended | 9 ft 11 in / 3.02 m | 24 ft 1 in / 7.34 m |
Power System
| Component | Specification |
|---|---|
| Power Type | Diesel |
| Engine Options | 74 hp / 55 kW Deutz TD2011 Turbo Diesel (T4i/Stage IIIA/CN III) |
| 74 hp / 55 kW Deutz TCD2.2L Turbo Diesel (Stage V) | |
| Hydraulic Tank Capacity | 110 gal / 416 L |
| Fuel Tank Capacity | 50 gal / 189.3 L |
Weight & Floor Loading
| Specification | Value |
|---|---|
| Total Weight | 55,000 lb / 24,948 kg |
| Tire Contact Pressure | 130 psi / 896 kPa |
| Occupied Floor Pressure – Axles Retracted | 337 psf / 16.12 kPa |
| Occupied Floor Pressure – Axles Extended | 175 psf / 8.39 kPa |
Sound & Vibration Levels
| Measurement Point | Level |
|---|---|
| Sound Pressure (Ground Workstation) | 91 dBA |
| Sound Pressure (Platform Workstation) | 75 dBA |
| Vibrations | < 2.5 m/s² |
Standard Features Summary
Power Features
- 74 hp Deutz Turbo Diesel Engine (Stage V Available)
- Cold Weather Package
- Diesel Air Intake Pre-cleaner
- Anti-restart Engine Protection
- Auto Engine Fault Shutdown
- In-cylinder Glow Plug
- Positive Air Shutdown System
Platform Features
- 8ft Tri-entry Platform with Side Swing Gate
- 10ft Rotating Jib
- 750lb Lift Capacity
- Self-leveling Platform
- Platform Load Sense System
- Proportional Controls
- 7.5kW AC Generator (110V/220V Options)
- 4 Steering Modes
Chassis Features
- XChassis Extendable Axles
- Lift Connect Telematics
- Rough Terrain Foam-filled Tires
- 2-speed Wheel Motors
- Positive Traction Drive
- Hydraulic Oil Cooler
- Dual Battery System
- Alarm Package with Flashing Beacon
Safety & Control Features
- Drive Enable System
- Lift Guard Contact Alarm
- Chassis Tilt Drive Function Cut-out
- Descent, Tilt and Motion Alarm
- Tech Pro Link Connector
- On-board Diagnostic System
- Horn and Light Package
Key Advantages
Rotating Jib System
- 10ft/3.05m Rotating Jib with 135° vertical and 60° horizontal rotation
- Enhanced positioning capabilities for complex work environments
- Improved access around obstacles
XChassis Technology
- Extendable Axles for enhanced stability
- Reduced transport footprint when retracted
- Improved maneuverability with extended configuration
High Capacity & Reach
- 750lb/340kg Lift Capacity for tools and materials
- 80ft Horizontal Reach for extended access
- 186ft Working Height for ultra-high applications
Compliance Standards
- CE Marking
- UKCA Certification
- Telescopic Boom Lifts Classification
Available Model Configurations
| Model | Engine | Generator | Features |
|---|---|---|---|
| SX-180 Standard | Stage V Deutz | – | 4WD, Basic Configuration |
| SX180001CV0026 | Stage V Deutz | 110V 7.5kW AC | 4WD, Control Box Cover |
| SX180001CV0025 | Stage V Deutz | 220V 7.5kW AC | 4WD, Control Box Cover |
